The NEW APC AP7801 Metered Rack PDU offers 8x NEMA 5-15 power output connections at 120V. It features a management interface with SNMP, Telnet, and WebUI capabilities through an RJ45 and RJ-11 serial port.
The input connection is via a NEMA L5-20P plug compatible with voltages ranging from 100V to 120V at frequencies of 50/60 Hz. With a maximum load capacity of up to 1920VA and max current per phase set for regulatory derated input current in North America at 16A, this PDU is designed for efficient power distribution in various settings requiring reliable performance.
NEW APC AP7801 Metered Rack 120V 20A 8x NEMA 5-15 1U PDU
- Power Output Connections : 8x NEMA 5-15
- Power Output Voltage : 120V
- Management Interface : SNMP, Telnet and WebUI, 1x RJ45 1x RJ-11 Serial
- Input Connection : 1x NEMA L5-20P
- Input Voltage : 100V, 120V
- Input Frequency : 50/60 Hz
- Input Amperage : 20A
- Load Capacity : 1920VA
- Regulatory Derated Input Current (North America) : 16A
- Cord Length : 15 feet (4.57 meters)
- Rack Mounts : Included
- Form Factor : 1U
- Model Number : AP7801
- Part Number : AP7801
- Condition : New
- One (1) NEW APC AP7801 Metered Rack 120V 20A 8x NEMA 5-15 1U PDU as described above
