The Cisco C6824-X-LE-40G Catalyst 6800X switch offers 24x 10GB SFP+ ports and two dedicated QSFP+ uplinks supporting up to 40Gbps bandwidth. This modular unit accommodates two PSU slots, sold separately, providing scalable power options tailored for different deployment needs.
Its form factor is designed for high-density environments prioritizing enhanced connectivity through its advanced port configuration. Compatibility with various modules ensures flexibility across diverse network architectures requiring reliable data throughput at higher speeds.
Integrated management features facilitate monitored operations while ensuring compatibility within existing systems using the Catalyst platform ecosystem's consistent software foundation and feature set capabilities idealized by enterprises or public-facing institutions.
Cisco C6824-X-LE-40G: Cisco Catalyst 6824-X-Chassis and 2 x 40G (Standard Tables).
- Network Ports : 24x 10 Gigabit Ethernet SFP+
- Uplink Ports : 2x 40 Gigabit Ethernet QSFP
- Management Ports : 1x Management (LAN) RJ45, 1x Console RJ45, 1x USB Type A, 1x Mini-USB Type B
- VLAN's : 4094
- IPv4 Routes : 256000
- IPv6 Routes : 128000
- IPv4 Routes (Multicast) : 128000
- IPv6 Routes (Multicast) : 64000
- Power Supplies Included : 2x PSU Slots - None Included - ordered separately
- Power Supply Options : C6840-X-750W-AC, C6840-X-750W-DC, C6840-X-1100W-AC, C6840-X-1100W-DC
- Switching Capacity : 160 Gbps
- Forwarding Rate : up to 120 Mpps
- MAC Address Table Size : 128,000
- IPv4 Routing : up to 120 Mpps
- DRAM and Flash : 4 GB RAM
- Model Number : C6824-X-LE-40G
- Part Number : C6824-X-LE-40G, C6824-X-LE-40G=, C6824-X-LE-40G-WS
- Condition : New
- One (1) NEW Cisco C6824-X-LE-40G Catalyst 6800X 24x 10GB SFP+ 2x 40GB QSFP+ Switch as described above
