NEW Cisco C9200L-48P-4X-A Catalyst 9200L 48x 1GB PoE+ RJ-45 4x 10GB SFP+ Switch
New

NEW Cisco C9200L-48P-4X-A Catalyst 9200L 48x 1GB PoE+ RJ-45 4x 10GB SFP+ Switch

Ask for quote
Shipping: OVERNIGHT OPTION
Cutoff Ground / 3 day / 2 day - 2pm PT, Cutoff Overnight - 5pm PT. Overnight orders after 4pm PT require approval. Call 800-430-6950 to confirm overnight orders after 4pm PT.
Condition: New
New in Original Manufacturers Box. Sold with warranty from NetworkTigers or the manufacturer.
Warranty: 365 days
Warranty coverage period
SKU: NSN-3655
UPC: 889728170192

Overview

The Cisco C9200L-48P-4X-A is a powerful and efficient network switch designed for modern businesses. With its 48 PoE+ RJ-45 ports, it can provide both data connectivity and power to compatible devices through Ethernet cables. It features four 10GB SFP+ ports for high-speed uplink connections.

This switch offers impressive performance with a switching capacity of 176 Gbps and a forwarding rate of 261.9 Mpps. It ensures smooth data transfer even in demanding network environments.

With the ability to deliver up to 740W (with one PSU) or an extended budget of 1440W (with two PSUs), this switch provides ample power for various networking needs.

Cisco C9200L-48P-4X-A: Catalyst 9200L 48x 1Gb RJ45 PoE+ ports, 4x10G SFP+ uplink ports.


Specifications

  • Network Ports : 48x 1 Gigabit Ethernet PoE+ RJ-45
  • Uplink Ports : 4x 10 Gigabit Ethernet SFP+
  • Management Ports : 1x RJ-45 Console, 1x Gigabit Management, 2x USB, 1x Mini USB
  • Stacking Ports : StackWise 80 possible through the use of C9200L-STACK-KIT - ordered separately.
  • Stacking Options : Stacking Bandwidth up to 160 Gbps - Mixed stacking is not supported. You cannot stack fixed (C9200L SKUs) with modular (C9200 SKUs) models, or other Catalyst switches
  • Stacking Cable Options : STACK-T4-50CM, STACK-T4-1M, STACK T4-3M
  • Switch Version : Network Advantage
  • Fan Module Options : Fixed
  • Power Supplies Included : 1x PWR-C5-1KWAC Included - 2x Slots - 2nd Power Supply ordered separately
  • Power Supply Options : PWR-C5-125WAC, PWR-C5-600WAC, PWR-C5-1KWAC, PWR-C5-BLANK - Not Included
  • PoE Budget : 740W (1PSU), 1440W (2PSU)
  • Switching Capacity : 176 Gbps
  • Forwarding Rate : 261.9 Mpps
  • MAC Address Table Size : 16,000
  • VLAN ID's : 4096
  • DRAM and Flash : 2 GB DRAM, 4 GB Flash
  • Model Number : C9200L-48P-4X-A
  • Part Number : C9200L-48P-4X-A, C9200L-48P-4X-A=, C9200L-48P-4X-A-WS
  • Condition : New


Included

  • One (1) NEW Cisco C9200L-48P-4X-A Catalyst 9200L 48x 1GB PoE+ RJ-45 4x 10GB SFP+ Switch as described above
