The Cisco C9300-24U-A is a high-performance switch designed to meet the needs of modern networking environments. With 24 UPoE RJ-45 ports and one module slot, it provides numerous connectivity options for various devices.
This switch comes with a PoE budget of 830W (1180W with an additional 350W PSU), ensuring that your connected devices receive ample power. It supports up to two PSUs, allowing for redundancy in case of power failure.
With a switching capacity of 208 Gbps (688 Gbps when stacked) and a forwarding rate of 154.76 Mpps (511.90 Mpps when stacked), this switch can handle heavy network traffic without any loss in performance.
Cisco C9300-24U-A: Catalyst 9300 24x 1Gb UPOE ports.
- Network Ports : 24x 1 Gigabit Ethernet UPoE RJ-45
- Product Family : Catalyst 9300 Series
- Management Ports : 1x Management Console RJ-45, 1x Management Console RJ-45, 1x USB 3.0 SSD
- Stacking Ports : 2x StackWise 480 Ports (480 Gbps Stacking Bandwidth), 2x StackPower Ports
- Stack Members : Up to eight switches can be connected in the stack | Supported stack members = Other C9300 SKUs with same license level - C9300 higher scale SKUs only stack with other like higher scale models
- Stacking Cable Options : STACK-T1-50CM, STACK-T1-1M, STACK-T1-3M, CAB-SPWR-30CM, CAB-SPWR-150CM - Cables sold separately
- Module Slots : 1x Expansion Module Slot - Modules are not included
- Module Options : C9300-NM-4G, C9300-NM-8X, C9300-NM-2Q - Not Included - Sold Separately - Please note, existing 3850 network modules are also supported in the Cisco Catalyst 9300 Series platforms.
- Switch Version : Network Advantage
- Fan Module Options : 3x FAN-T2 Field Replaceable Fan Modules Included
- Power Supplies Included : 1x PWR-C1-1100WAC 1100W AC PSU Included - 2x PSU Slots - 2nd PSU ordered separately
- Power Supply Options : PWR-C1-1100WAC, PWR-C1-715WAC, PWR-C1-350WAC
- PoE Budget : 830W with 1x 1100W AC PSU - 1180W (with 350W 2nd PSU), 1440W (with 715W 2nd PSU), 1440W (with 1100W 2nd PSU)
- Switching Capacity : 208 Gbps (688 Gbps with Stacking)
- Forwarding Rate : 154.76 Mpps (511.90 Mpps with Stacking)
- MAC Address Table Size : 32,000
- Model Number : C9300-24U-A
- Part Number : C9300-24U-A, C9300-24U-A=, C9300-24U-A-WS
- Condition : Seller refurbished
- One (1) Seller Refurbished Cisco C9300-24U-A 24x Catalyst 9300 24x 1GB UPoE RJ-45 1x Module Slot Switch as described above
- One (1) Notched Power Cord Included
- One (1) AC Power Supply Included
- Three (3) Fan Modules Included
- One (1) Set of Rack Mount Brackets Included
- Manuals or product brochures are not included. Software or Firmware DVDs or CDs are not included
Product information and installation instructions may be found on the manufacturer's website or the web. Software or firmware updates may be available through the manufacturer's website - Transceiver Modules Not Included
- Network Modules Not Included
