The Cisco C9300X-12Y-E Catalyst 9300X switch offers Module Slots -1x Expansion Module Slot, supporting options such as C9300X-NM-8M and others. This model features a Switching Capacity of 1,000 Gbps (2,000 Gbps w/ Stacking) and Forwarding Rate of 744.04 Mpps (1488 Mpps w/ Stacking).
The MAC Address Table Size is listed at 32,000 entries for efficient networking performance. With its versatile module options and high-speed capabilities, the Cisco C9300X-12Y-E is designed to meet the demands of modern networks seeking reliable connectivity solutions across various applications.
Cisco C9300X-12Y-E Catalyst 9300X 12x 25GB SFP28 1x Expansion Module Slot Switch
- Network Ports : 12x 25 Gigabit Ethernet SFP28
- Management Ports : 1x USB 2.0, 1x RJ45 Management
- Stacking Ports : 2x StackWise-1T Ports (1Tbps Stacking Bandwidth), 2x StackPower+ Ports - Cables sold separately
- Stacking Options : Up to 8 Members in a stack (max of 448 ports). Mixed stacking between Catalyst 9300X and 9300 models | Up to 4 switches can be configured in a StackPower stack with the special connector at the back of the switch. C9300X models support StackPower+.
- Stacking Cable Options : StackWise Options are STACK-T1-50CM, STACK-T1-1M, STACK-T1-3M - StackPower Options are CAB-SPWR-30CM, CAB-SPWR-150CM
- Module Slots : 1x Expansion Module Slot - Modules Not Included
- Module Options : C9300X-NM-8M, C9300X-NM-8Y, C9300X-NM-2C, C9300X-NM-4C, C9300-NM-4G, C9300-NM-4M, C9300-NM-8X, C9300-NM-2Q, C9300-NM-2Y
- Switch Version : Network Essentials
- AirFlow Direction : Front-to-Back Airflow (Port Side Intake)
- Fan Module Options : 3x FAN-T2 Fan Modules Included
- Power Supplies Included : 1x 715W AC PSU Included (PWR-C1-715WAC) - 2x Slots - 2nd PSU ordered separately
- Power Supply Options : PWR-C1-350WAC-P, PWR-C1-715WAC-P, PWR-C1-1100WAC-P, PWR-C1-1900WAC-P
- PoE Budget : No PoE
- Switching Capacity : 1,000 Gbps (2,000 Gbps w/ Stacking)
- Forwarding Rate : 744.04 Mpps (1488 Mpps w/ Stacking)
- MAC Address Table Size : 32,000
- Model Number : C9300X-12Y-E
- Part Number : C9300X-12Y-E
- Condition : Seller refurbished
- One (1) Seller refurbished Cisco C9300X-12Y-E Catalyst 9300X 12x 25GB SFP28 1x Expansion Module Slot Switch as described above
- One (1) Power Cord Included
- One (1) AC Power Supply Included
- Three (3) Fan Modules Included
- One (1) Set of Rack Mount Brackets Included
- Manuals or product brochures are not included. Software or Firmware DVDs or CDs are not included
Product information and installation instructions may be found on the manufacturer's website or the web. Software or firmware updates may be available through the manufacturer's website - Transceiver Modules Not Included
