NEW Cisco C9500-32QC-A Catalyst 9500 32x 40GB QSFP+ Switch
New

NEW Cisco C9500-32QC-A Catalyst 9500 32x 40GB QSFP+ Switch

Ask for quote
Shipping: OVERNIGHT OPTION
Cutoff Ground / 3 day / 2 day - 2pm PT, Cutoff Overnight - 5pm PT. Overnight orders after 4pm PT require approval. Call 800-430-6950 to confirm overnight orders after 4pm PT.
Condition: New
New in Original Manufacturers Box. Sold with warranty from NetworkTigers or the manufacturer.
Warranty: 365 days
Warranty coverage period
SKU: NSN-4268
UPC: 889728142632

Overview

The Cisco C9500-32QC-A Catalyst 9500 is a high-performance switch designed to meet the demands of modern network infrastructures. With its front-to-back airflow design, this switch ensures efficient cooling and optimal performance in data centers.

This powerful switch offers a switching capacity of up to 3.2 Tbps, allowing for seamless data transfer and improved network speeds. It also boasts a forwarding rate of up to 1 Bpps (billion packets per second), ensuring fast and reliable packet delivery across your network.

With an impressive MAC address table size of 82,000 entries, the C9500-32QC-A can efficiently handle large-scale networks with ease. This helps ensure smooth connectivity even in complex networking environments.

Cisco C9500-32QC-A: Cisco Catalyst 9500 Series high performance 32-port 40G switch.


Specifications

  • Network Ports : 32x 40 Gigabit Ethernet QSFP+
  • Product Family : Catalyst 9500 Series
  • Management Ports : 1x USB, 1x Mini USB, 1x RJ45 Console, 1x Gigabit Management
  • Stacking Options : StackWise Virtual (SWV) is supported on this switch. The software is designed to connect two physical switches so they act like a single logical unit.
  • Stacking Cable Options : The user can stack 2x C9500 switches together using a high speed Ethernet cable.
  • Switch Version : Network Advantage Version
  • AirFlow Direction : Front-to-Back Airflow
  • Fan Module Options : 4x C9K-T1-FANTRAY Fans Modules Included - can operate with up to one individual fan failure
  • Power Supplies Included : 2x Slots - 1x C9K-PWR650WAC-R Power Supply Included - 2nd Power Supply ordered separately
  • Power Supply Options : C9K-PWR650WAC-R, C9K-PWR930WDC-R
  • Switching Capacity : Up to 3.2 Tbps
  • Forwarding Rate : Up to 1 Bpps
  • MAC Address Table Size : 82,000
  • DRAM and Flash : 4GB DDR2 SDRAM, 16GB Flash
  • Model Number : C9500-32QC-A
  • Part Number : C9500-32QC-A, C9500-32QC-A=, C9500-32QC-A-WS
  • Condition : New


Included

  • One (1) NEW Cisco C9500-32QC-A Catalyst 9500 32x 40GB QSFP+ Switch as described above
