NEW Arista CCS-720XP-48ZC2-2F 48x MultiGB PoE RJ45 4x SFP28 2x QSFP28 F-B Switch

Ask for quote
Shipping: OVERNIGHT OPTION
Cutoff Ground / 3 day / 2 day - 2pm PT, Cutoff Overnight - 5pm PT. Overnight orders after 4pm PT require approval. Call 800-430-6950 to confirm overnight orders after 4pm PT.
Condition: New
New in Original Manufacturers Box. Sold with warranty from NetworkTigers or the manufacturer.
Warranty: 365 days
Warranty coverage period
SKU: NSN-4102

Overview

The NEW Arista CCS-720XP-48ZC2-2F switch features a PoE budget of 909W with default power supplies, and up to 1787W with dual AC power supplies. Switching capacity is rated at 440 Gbps (880 Gbps full duplex) with a forwarding rate of 654 Mbps.

The switch supports up to 112,000 MAC addresses and has an ultra-low latency of just 1.2 microseconds. It offers versatile connectivity options including multiple MultiGB RJ45 ports, SFP28 for high-speed networking, as well as QSFP28 interfaces for increased bandwidth capabilities.

For reliable performance in various environments requiring efficient data processing and network stability the Arista CCS-720XP series stands out by delivering consistent throughput rates supported by its powerful hardware design."

NEW Arista CCS-720XP-48ZC2-2F 48x MultiGB PoE RJ45 4x SFP28 2x QSFP28 F-B Switch


Specifications

  • Network Ports : 40x 100MB - 2.5 Gigabit Ethernet PoE RJ45 (30W 802.3af/at), 8x 100M - 5 Gigabit Ethernet PoE RJ45 (60W 802.3bt)
  • Uplink Ports : 4x 25 Gigabit Ethernet SFP28, 2x 100 Gigabit Ethernet QSFP28
  • Management Ports : 1x USB, 1x RJ45 Console, 1x Gigabit Management
  • Product Family : 720XP Series
  • Packet Buffer : 6MB
  • Switching Bandwidth : 1120 Gbps
  • CPU : Dual Core-x86
  • VLAN ID's : 4096
  • Switch Version : Arista EOS
  • AirFlow Direction : Front-to-Back Airflow
  • Fan Module Options : 3x FAN-7000-F Fan Modules Included - Front-to-Back Airflow
  • Power Supplies Included : 2x Slots - 2x PWR-1021-AC-RED 1050W AC Power Supply Included - Front-to-Back Airflow
  • Power Supply Options : Other PSU Options are PWR-621-AC-RED (650W AC), PWR-521-DC-RED (500W DC)
  • PoE Budget : 909W (w/ Default 1x 1050W AC PSU), 1787W (w/ Dual 1050W AC PSU's) - 1047W w/ Dual 650W AC, 794W w/ Dual 500W DC PSU's
  • Throughput (FDX) : 440 (880) Gbps
  • Forwarding Rate : 654 Mpps
  • MAC Address Table Size : 112,000
  • Latency : 1.2 microseconds
  • DRAM and Flash : 4GB Flash, 4GB System Memory
  • Model Number : CCS-720XP-48ZC2-2F
  • Part Number : CCS-720XP-48ZC2-2F
  • Condition : New


Included

  • One (1) NEW Arista CCS-720XP-48ZC2-2F 48x MultiGB PoE RJ45 4x SFP+ 2x QSFP28 F-B Switch as described above
