The Arista DCS-7280PR3-24-F is a 1RU 7280R3 switch router with 24 400GbE OSFP ports. Every port is 400GbE, and breakout options reach 96 100G, 192 50G, 24 40G or 192 25G/10G interfaces.
Capacity is 9.6 Tbps (19.2 Tbps full duplex) with 4 Bpps forwarding, and latency starts at 3.8 microseconds according to Arista. A 16 GB packet buffer gives headroom for congestion in spine and interconnect roles. Route scale is profile dependent, with up to 1450K IPv4 routes in the L3 profile plus up to 1792K more using FlexRoute, and 224K MAC addresses.
Two hot-swap 1500 W PWR-1511 AC supplies are included (1+1); the PWR-1511-DC-RED is the DC option. Three hot-swap FAN-7011H-F fans provide N+1 cooling. Airflow is front-to-back (port-side intake) only, with no back-to-front version listed. Typical power is 650 W, maximum 1100 W.
The switch weighs 28 lb and measures 17.3 x 22.6 x 1.72 inches. Advanced Layer 3 features such as BGP and OSPF need an Arista Enhanced L3 license, which is not included and is available from Arista partners.
Matching spares include the PWR-1511-AC-RED power supply.
Check your rack depth, power feeds, and cold-aisle orientation before you order, since the airflow direction is set by the fans and power supplies installed.
This seller refurbished DCS-7280PR3-24-F is tested, working, and covered by the NetworkTigers one-year warranty.
- Network Ports : 24x 400GbE OSFP (max 96x 100G / 192x 50G / 24x 40G / 192x 25G-10G via breakout)
- Port Supported Speeds : 400G, 100G, 50G, 40G, 25G, 10G
- Management Ports : 1x 100/1000 mgmt, 1x RS-232 RJ-45 console, 1x USB
- SSD : 120GB (included with 64GB system memory config)
- AirFlow Direction : Front-to-back (port-side intake)
- Fan Modules Included : 3 hot-swap (N+1), FAN-7011H-F
- Fan Module Options : FAN-7011H-F
- Power Supplies Included : 2x AC 1500 W PWR-1511 (hot-swap, 1+1)
- Power Supply Options : PWR-1511-AC-RED, PWR-1511-DC-RED (1500 W, forward airflow)
- Switching Capacity : 9.6 Tbps (19.2 Tbps full duplex)
- Forwarding Rate : 4 Bpps
- MAC Address Table Size : 448,000 (Balanced) / 128,000 (L3) / 736,000 (R3K Balanced) / 160,000 (R3K L3)
- Max IPv4 Host Entries : 896,000 (Balanced) / 256,000 (L3)
- Max IPv4 LPM Routes : 704,000 (Balanced) / 1,300,000 (L3)
- Multicast routes : 448,000 (Balanced) / 128,000 (L3)
- Virtual interfaces (VLANs) : 4,096
- Packet Buffer : 16GB
- Latency : from 3.8 microseconds
- DRAM and Flash : 8 GB DRAM (64 GB optional), 8 GB flash, 120 GB SSD with 64 GB option, quad-core x86
- Model Number : DCS-7280PR3-24-F
- Part Number : DCS-7280PR3-24-F
- Condition : Seller refurbished
- One (1) Seller Refurbished Arista DCS-7280PR3-24-F 7280R3 Series 24x 400 Gigabit OSFP F-B Air Switch Router as described above
- Two (2) Power Cords Included
- Two (2) AC Power Supplies Included
- Four (4) Fan Modules Included
- One (1) Set of Rack Mount Brackets Included
- Manuals or product brochures are not included. Software or Firmware DVDs or CDs are not included
Product information and installation instructions may be found on the manufacturer's website or the web. Software or firmware updates may be available through the manufacturer's website - Transceiver Modules Not Included
