The Arista DCS-7280SR3K-48YC8-F is the large-route 7280R3K version of the 48-port 25GbE switch router. This 1RU unit has 48 1/10/25GbE SFP ports and 8 100GbE QSFP100 uplinks, which also run as 8 40G or 16 50G, for up to 80 25G/10G interfaces.
Route scale is profile dependent, reaching up to 3950K IPv4 routes in L3-XXXL or 2850K in L3-XXL, with up to 384K MAC addresses; the L3-Host-XL profile supports 192K ARP entries. Capacity is 2.0 Tbps (4.0 Tbps full duplex) at 1 Bpps, Arista lists latency from 3.8 microseconds, and the packet buffer is 4 GB. MACsec is on separate SR3MK models, not this SKU.
Two hot-swap 500 W PWR-511 AC supplies (1+1) and two hot-swap fans (N+1) are included. Airflow is front-to-back (port-side intake), with PWR-511-AC-RED supplies and FAN-7011M-F fans. Arista also sells the back-to-front DCS-7280SR3K-48YC8-R, so match your rack. Typical power is 154 W, maximum 324 W.
The switch weighs 20.2 lb and measures 17.3 x 18.38 x 1.72 inches. Advanced Layer 3 features such as BGP and OSPF need an Arista Enhanced L3 license, which is not included and is available from Arista partners.
Matching spares include the FAN-7011M-F fan module.
This seller refurbished DCS-7280SR3K-48YC8-F is tested, working, and covered by the NetworkTigers one-year warranty.
- Network Ports : 48x 1/10/25GbE SFP
- Uplink Ports : 8x 100GbE QSFP100 (max 8x 40G / 16x 50G; 80x 25G-10G total)
- Management Ports : 1x 100/1000 mgmt, 1x RS-232 RJ-45 console, 1x USB
- Switch Version : 7280SR3K (Large Routes)
- System Memory : 64 GB DRAM, 120 GB SSD, quad-core x86
- AirFlow Direction : Front-to-back (port-side intake)
- Fan Modules : 2 hot-swap (N+1), FAN-7011M-F / FAN-7011M-R
- Power Supplies : 2x AC 500 W PWR-511 (hot-swap, 1+1)
- Switching Capacity : 2.0 Tbps (4.0 Tbps full duplex)
- Forwarding Rate : 1 Bpps
- MAC Address Table Size : 224,000 (L3) / 256,000 (Balanced) / 256,000 (R3K Balanced) / 384,000 (R3K L3-XXXL)
- Max IPv4 LPM Routes : 1,450,000 (L3) / 800,000 (Balanced) / 3,950,000 (R3K L3-XXXL)
- Max IPv6 LPM Routes : 433,000-483,000 (L3) / 250,000-267,000 (Balanced)
- Multicast Routes : 112,000 (L3) / 112,000 (Balanced) / 192,000 (R3K L3-XXXL)
- VLANs Supported : 4,096
- Packet Buffer : 4GB
- Latency : from 3.8 microseconds
- CPU : Quad-Core x86
- Model Number : DCS-7280SR3K-48YC8-F
- Part Number : DCS-7280SR3K-48YC8-F
- Condition : Seller refurbished
- One (1) Seller refurbished Arista DCS-7280SR3K-48YC8-F 48x 25GB SFP28 8x 100GB QSFP28 F-B Air Switch Router as described above
- Two (2) AC Power Supplies Included
- Two (2) Power Cords Included
- Two (2) Fan Modules Included
- One (1) Set of Rack Mount Brackets Included
- Manuals or product brochures are not included. Software or Firmware DVDs or CDs are not included
Product information and installation instructions may be found on the manufacturer's website or the web. Software or firmware updates may be available through the manufacturer's website - Transceiver Modules Not Included
