Cisco DS-C9396S-96IK9 MDS 9300 96x 16G FC SFP+ (96x Active) PSI Air Switch

Cisco DS-C9396S-96IK9 MDS 9300 96x 16G FC SFP+ (96x Active) PSI Air Switch

Ask for quote
Shipping: OVERNIGHT OPTION
Cutoff Ground / 3 day / 2 day - 2pm PT, Cutoff Overnight - 5pm PT. Overnight orders after 4pm PT require approval. Call 800-430-6950 to confirm overnight orders after 4pm PT.
Condition: Seller refurbished
Pre-owned, tested by qualified techs, working, reset-to-factory default, grade A condition, and parts needed for normal functions are included (as described in the listing).
Warranty: 365 days
Warranty coverage period
SKU: NSB-6890

Overview

The Cisco DS-C9396S-96IK9 is a 96-port Fibre Channel switch within the MDS 9300 Series, offering connectivity for SAN deployments. It supports up to 16Gbps port speeds with active SFP+ links across all ports.

Designed for scalability and high availability, it enables modern data center storage networking through its compact form factor and robust performance capabilities. The switch provides low-latency operations critical in minimizing bottlenecks during data transfers or intense workloads shared in virtualization environments or big data applications.

Cisco DS-C9396S-96IK9: Cisco MDS 9396S 16G FC switch, w/ 96 active ports (port-side intake).


Specifications

  • Network Ports : 96x 16 Gigabit Fibre Channel SFP+ (96x Active)
  • Upgrades : Upgraded as needed with the 12-port Cisco MDS 9396S On-Demand Port Activation license to also support configurations of 60, 72, 84, and 96 enabled ports.
  • Management Ports : 1x RJ45 Management, 1x USB, 1x RS-232
  • Fan Modules AirFlow Direction : 1x Hot Swappable Fan Tray w/ integrated temp and power management - Port Side Intake Airflow
  • Power Supplies Included : 2x Hot Swappable Dual Redundant Power Supplies - Port Side Intake Airflow
  • Series : MDS 9300 Series
  • Rack Mounts : Included (2-RU)
  • Model Number : DS-C9396S-96IK9
  • Part Number : DS-C9396S-96IK9, DS-C9396S-96IK9=, DS-C9396S-96IK9-WS
  • Condition : Seller refurbished

Datasheet

More information on this Cisco DS-C9396S-96IK9.

Included

  • One (1) Seller Refurbished Cisco DS-C9396S-96IK9 MDS 9300 96x 16G FC SFP+ (96x Active) PSI Air Switch as described above
  • Two (2) Power Cords Included
  • Two (2) AC Power Supplies Included
  • One (1) Fan Module Included
  • One (1) Set of Rack Mount Brackets Included

Not Included

  • Manuals or product brochures are not included. Software or Firmware DVDs or CDs are not included
    Product information and installation instructions may be found on the manufacturer's website or the web. Software or firmware updates may be available through the manufacturer's website
  • Transceiver Modules Not Included
