NEW Juniper EX4300-48MP 24x 1GB MultiGB PoE++ RJ45 4x 40GB QSFP+ F-B Air Switch
New

NEW Juniper EX4300-48MP 24x 1GB MultiGB PoE++ RJ45 4x 40GB QSFP+ F-B Air Switch

$ 1,586.99
Only 1 remaining
In stock means that we have the product available to meet your delivery commitment. If it is on the web site, it is available for sale and we can ship it that day.
  Call if you need more
Shipping: OVERNIGHT OPTION
Cutoff Ground / 3 day / 2 day - 2pm PT, Cutoff Overnight - 5pm PT. Overnight orders after 4pm PT require approval. Call 800-430-6950 to confirm overnight orders after 4pm PT.
Condition: New
New in Original Manufacturers Box. Sold with warranty from NetworkTigers or the manufacturer.
Warranty: 365 days
Warranty coverage period
SKU: NSN-3795
UPC: 832938083950

Overview

The Juniper EX4300-48MP is a powerful and versatile switch for high-performance networking. With 24x 1GB RJ45 ports, this switch provides reliable device connectivity. It features multi-gigabit RJ45 ports that allow faster data transfer rates up to 10Gbps.

Equipped with four 40GB QSFP+ ports, the EX4300-48MP offers flexibility when connecting to higher-speed networks or stacking multiple switches together. It also supports Power over Ethernet (PoE) with a budget of up to 1100W, making it suitable for powering PoE-enabled devices such as IP cameras and wireless access points.

This Juniper switch has an impressive switching capacity of 960 Gbps, ensuring efficient network traffic handling. The forwarding rate stands at a staggering speed of 714 Mpps so that you can experience smooth data transmission without any bottlenecks.

With its MAC Address Table Size reaching up to 64,000 entries, one has enough space for all your connected devices.

Juniper EX4300-48MP: 24-port 10/100/1000BASE-T, 24-port 100/1000/2500/5000/10000BASE-T, 95W PoE++, 1400W AC PS (provides up to 1100 W PoE+ power) (QSFP+ DAC for Virtual Chassis ordered separately).


Specifications

  • Network Ports : 24x 1 Gigabit Ethernet RJ45, 24x MultiGigabit Ethernet 95W PoE++ RJ45 (100/1000/2500/5000/10000BASE-T)
  • Uplink Ports : 4x 40 Gigabit Ethernet QSFP+
  • Management Ports : 1x RJ45 Management, 1x RJ45 Console, 1x USB
  • Module Slots : 1x Slot - None Included - Sold Separately
  • Module Options : EX-UM-2QSFP-MR, EX-UM-4SFPP-MR - Not included
  • Switch Version : Junos OS
  • AirFlow Direction : AFO - Front-to-back airflow
  • Fan Module Options : 2x EX4300-48MP-FAN
  • Power Supplies Included : 1x JPSU-1400-AC-AFO - 1400W AC Included - 2x Slots - 2nd Power Supply ordered separately.
  • PoE Budget : 1100W
  • Switching Capacity : 960 Gbps
  • Forwarding Rate : 714 Mpps
  • MAC Address Table Size : 64,000
  • Model Number : EX4300-48MP
  • Part Number : EX4300-48MP
  • Condition : New


Included

  • One (1) NEW Juniper EX4300-48MP 24x 1GB RJ45 MultiGB RJ45 4x 40GB QSFP+ F-B Air Switch as described above
