NEW Brocade Ruckus ICX7250-48 48x 1GB RJ45 8x 1GB SFP Side-to-Back Air Switch
New

NEW Brocade Ruckus ICX7250-48 48x 1GB RJ45 8x 1GB SFP Side-to-Back Air Switch

Ask for quote
Shipping: OVERNIGHT OPTION
Cutoff Ground / 3 day / 2 day - 2pm PT, Cutoff Overnight - 5pm PT. Overnight orders after 4pm PT require approval. Call 800-430-6950 to confirm overnight orders after 4pm PT.
Condition: New
New in Original Manufacturers Box. Sold with warranty from NetworkTigers or the manufacturer.
Warranty: 365 days
Warranty coverage period
SKU: NSN-7909
UPC: 088611705552

Overview

The NEW Brocade Ruckus ICX7250-48 switch delivers robust performance and scalability with 48x 1GbE RJ45 ports and eight 1GbE SFP uplinks. It efficiently handles high-bandwidth tasks in networks by supporting a switching capacity of up to 256 Gbps and a forwarding rate of up to 190 Mpps.

The device accommodates growing network demands with its MAC address table that supports entries for up to 16,384 addresses, ensuring effective traffic routing across devices connected within the system. Its side-to-back air flow enhances cooling efficiency while supporting operational reliability in dense setups or stacked environments where consistent thermal management is necessary.

NEW Brocade Ruckus ICX7250-48 48x 1GB RJ45 8x 1GB SFP Side-to-Back Air Switch


Specifications

  • Network Ports : 48x 1 Gigabit Ethernet RJ45
  • Uplink Ports : 8x 1 Gigabit Ethernet SFP (upgradable to up to 8x 10GB SFP+ uplink/stacking-ports with license)
  • Management Ports : 1x RJ45 Management, 1x Mini USB, 1x Serial RJ45, 1x USB
  • Stacking Ports : Uplink ports can be used for stacking ONLY once upgraded to 10GB ports - ICX7250-2X10G-LIC-POD, ICX7250-8X10G-LIC-POD (licences not sold by NetworkTigers)
  • Packet Buffer : 4 MB
  • AirFlow Direction : Side to Back Airflow
  • Power Supplies Included : 1x Internal AC Power Supply
  • Max VLAN's : 4,096
  • Switching Capacity : 256 Gbps
  • Forwarding Rate : 190 Mpps
  • MAC Address Table Size : 16,384
  • Latency : 1.5 µs
  • DRAM and Flash : 2 GB DRAM, 2GB Flash
  • Model Number : ICX7250-48
  • Part Number : ICX7250-48
  • Condition : New


Included

  • One (1) NEW Brocade Ruckus ICX7250-48 48x 1GB RJ45 8x 1GB SFP Side-to-Back Air Switch as described above
