NEW Ruckus Brocade ICX7450-48 48x 1GB RJ45 Switch w/ 3x Expansion Module Slots
New

NEW Ruckus Brocade ICX7450-48 48x 1GB RJ45 Switch w/ 3x Expansion Module Slots

Ask for quote
Shipping: OVERNIGHT OPTION
Cutoff Ground / 3 day / 2 day - 2pm PT, Cutoff Overnight - 5pm PT. Overnight orders after 4pm PT require approval. Call 800-430-6950 to confirm overnight orders after 4pm PT.
Condition: New
New in Original Manufacturers Box. Sold with warranty from NetworkTigers or the manufacturer.
Warranty: 365 days
Warranty coverage period
SKU: NSN-8843
UPC: 818214937766

Overview

The NEW Ruckus Brocade ICX7450-48 is a 48-port Gigabit RJ45 switch offering three modular expansion slots for flexible uplink and stacking options. It supports optional modules like the ICX7400-4X1GF (4x 1GbE SFP), ICX7400-4X10GF (4x 10GbE SFP+), or the ICX7400-1X40GQ (one port, 40 GbE).

One module slot is located on the front panel, while two additional slots are at the rear of the unit. Delivering up to a switching capacity of 336 Gbps and a forwarding rate of up to 250 Mpps ensures robust data throughput in various applications.

NEW Ruckus Brocade ICX7450-48 48x 1GB RJ45 Switch w/ 3x Expansion Module Slots


Specifications

  • Network Ports : 48x 1 Gigabit Ethernet RJ45
  • Product Family : ICX 7450 Series (Ruckus, Previously Brocade)
  • Management Ports : 1x Mini-USB RS232 Serial port (Mini-B plug), 1x RJ45 Gigabit Ethernet Management port, 1x USB port
  • Stacking Ports : Possible through the use of ICX7400-1X40GQ Modules - Not Included
  • Module Slots : 3x Optional Modules slots for Uplink/Stacking - None Included - ordered separately (1x Module Slot on front of switch, 2x Module Slots on rear of switch)
  • Module Options : ICX7400-4X1GF (4x 1GB SFP), ICX7400-4X10GF (4x 10GB SFP+), ICX7400-4X10GC (4x 10GB RJ45), ICX7400-1X40GQ (1x 40GB Uplink/Stack), ICX7400-SERVICE-MOD (Service Module) - None Included
  • Fan Module Options : 2x Fan Module Slots - Not Included - Options are ICX-FAN10-E (F-B Airflow), ICX-FAN10-I (B-F Airflow)
  • Power Supplies Included : Not Included - 2x PSU Slots
  • Power Supply Options : RPS16-E (PoE 1,000W AC F-B Air), RPS16-I (PoE 1,000W AC B-F Air) - Ordered Separately
  • Stack Members : It offers market-leading stacking density with up to 12 switches (576x 1 GbE and 144x 1/10 GbE ports) per stack and combines chassis-level performance with “pay as you grow” scalability of a stackable solution
  • Switching Capacity : 336 Gbps
  • Forwarding Rate : 250 Mpps
  • MAC Address Table Size : 32,768
  • Model Number : ICX7450-48
  • Part Number : ICX7450-48
  • Condition : New


Included

  • One (1) NEW Ruckus Brocade ICX7450-48 48x 1GB RJ45 Switch w/ 3x Expansion Module Slots as described above
