Ruckus ICX7550-48 ICX 7550 Series 48x 1GB RJ45 2x 40GB QSFP+ Switch

Ruckus ICX7550-48 ICX 7550 Series 48x 1GB RJ45 2x 40GB QSFP+ Switch

Ask for quote
Shipping: OVERNIGHT OPTION
Cutoff Ground / 3 day / 2 day - 2pm PT, Cutoff Overnight - 5pm PT. Overnight orders after 4pm PT require approval. Call 800-430-6950 to confirm overnight orders after 4pm PT.
Condition: Seller refurbished
Pre-owned, tested by qualified techs, working, reset-to-factory default, grade A condition, and parts needed for normal functions are included (as described in the listing).
Warranty: 365 days
Warranty coverage period
SKU: NSB-7414

Overview

The Ruckus ICX7550-48 switch delivers 48× 1GbE RJ45 ports and two 40GbE QSFP+ uplinks, supporting a switching capacity of 416 Gbps with a forwarding rate of 309 Mpps.

The MAC address table offers three profiles: profile1 supports up to 16,000 addresses, profile2 extends to 114,000 addresses, while profile3 provides 32,000 entries. This device enhances connectivity in enterprise deployments by providing high-speed data transfer capabilities.

Its robust design enables reliable performance across multiple networking applications. Scalable stacking features simplify management for growing networks without requiring additional hardware investments for expansion.

Ruckus ICX7550-48 ICX 7550 Series 48x 1GB RJ45 2x 40GB QSFP+ Switch


Specifications

  • Network Ports : 48x 1 Gigabit Ethernet RJ45
  • Uplink Ports : 2x 40 Gigabit Ethernet QSFP+ (Used for Stacking)
  • Management Ports : 1x RJ45 Out of Band Management, 1x USB Type C
  • Stacking Ports : Uplink ports act as stacking ports.
  • Stacking Density : 12 Switches
  • Stacking Bandwidth : 960 Gbps
  • Fan Module Options : 3x Hot-Swap Fan Slots (N+1 redundancy) - Fans not included - ordered separately - Options are ICX-FAN12-E (Front-Back), ICX-FAN12-I (Back-Front)
  • Power Supplies Included : 2x 400W AC PSU Slots - PSU's ordered separately
  • Power Supply Options : RPS21-E (Front-Back), RPS21-I (Back-Front) - Not Included
  • Switching Capacity : 416 Gbps
  • Forwarding Rate : 309 Mpps
  • MAC Address Table Size : 16,000 (profile1), 114,000 (profile2), 32,000 (profile3)
  • Model Number : ICX7550-48
  • Part Number : ICX7550-48
  • Condition : Seller refurbished

Datasheet

More information on this Ruckus ICX7550-48.

Included

  • One (1) Seller refurbished Ruckus ICX7550-48 ICX 7550 Series 48x 1GB RJ45 2x 40GB QSFP+ Switch as described above
  • One (1) Set of Rack Mount Brackets Included

Not Included

  • Manuals or product brochures are not included. Software or Firmware DVDs or CDs are not included
    Product information and installation instructions may be found on the manufacturer's website or the web. Software or firmware updates may be available through the manufacturer's website
  • Power Supplies Not Included
  • Network Modules Not Included
  • Power Cord Not Included
  • Transceiver Modules Not Included
