The Ruckus ICX7550-48P-E2 switch is designed with 48 ports of Gigabit Ethernet connectivity, along with 2 ports for higher-speed network connections using QSFP+. With a switching capacity of 416 Gbps and a forwarding rate of 309 Mpps, this switch can efficiently handle high data traffic levels.
It supports up to 16,000 MAC addresses in profile1 configuration and scales up to accommodate even more devices in different configurations. This switch is a practical choice for organizations looking to expand their network capabilities while maintaining reliable performance.
Its PoE+ support ensures that compatible devices receive power over the Ethernet connection, reducing the need for additional power sources. The Ruckus ICX7550-48P-E2 offers flexibility and scalability for growing networks without compromising on speed or reliability.
Ruckus ICX7550-48P-E2 ICX 7550 48x 1GB PoE+ RJ45 2x 40GB QSFP+ F-B Air Switch
- Network Ports : 48x 1 Gigabit Ethernet PoE+ RJ45
- Uplink Ports : 2x 40 Gigabit Ethernet QSFP+
- Management Ports : 1x RJ45 Out of Band Management, 1x USB Type C
- Stacking Density : 12 Switches
- Stacking Bandwidth : 960 Gbps
- AirFlow Direction : Front-to-back, or back-to-front (depending on power supplies and fans installed)
- Fan Module Options : 3x Hot-Swap Fans (N+1 redundancy)
- Power Supplies Included : 2x PSU Slots - 2x 1200W AC PSU's included
- Switching Capacity : 416 Gbps
- Forwarding Rate : 309 Mpps
- MAC Address Table Size : 16,000 (profile1), 114,000 (profile2), 32,000 (profile3)
- Model Number : ICX7550-48P-E2
- Part Number : ICX7550-48P-E2
- Condition : Seller refurbished
- One (1) Seller refurbished Ruckus ICX7550-48P-E2 ICX 7550 48x 1GB PoE+ RJ45 2x 40GB QSFP+ F-B Air Switch as described above
- Two (2) Power Cords Included
- Two (2) AC Power Supplies Included
- Three (3) Fan Modules Included
- One (1) Set of Rack Mount Brackets Included
- Manuals or product brochures are not included. Software or Firmware DVDs or CDs are not included
Product information and installation instructions may be found on the manufacturer's website or the web. Software or firmware updates may be available through the manufacturer's website - Transceiver Modules Not Included
