NEW HPE J9540A 92x 1GB PoE+ RJ45 4x 1GB SFP 8x Open Mod Slots Switch w/ Premium
New

NEW HPE J9540A 92x 1GB PoE+ RJ45 4x 1GB SFP 8x Open Mod Slots Switch w/ Premium

Ask for quote
Shipping: OVERNIGHT OPTION
Cutoff Ground / 3 day / 2 day - 2pm PT, Cutoff Overnight - 5pm PT. Overnight orders after 4pm PT require approval. Call 800-430-6950 to confirm overnight orders after 4pm PT.
Condition: New
New in Original Manufacturers Box. Sold with warranty from NetworkTigers or the manufacturer.
Warranty: 365 days
Warranty coverage period
SKU: NSN-2518
UPC: 885631941508

Overview

The NEW HPE J9540A Switch offers 92x 1GB PoE+ RJ45 ports, along with 4x 1GB SFP and 8 open mod slots. With a premium design, it provides a PoE budget of up to 2760W.

The switch boasts impressive specifications including a switching capacity of up to -758.4 Gbps and forwarding rate of -564.2 Mpps for efficient data transfer speeds. It also features a MAC Address Table Size of 64000 for enhanced network management capabilities.

With low latency at less than <3.7 μs (FIFO-64 byte packets), the HPE J9540A ensures fast response times in high-demand networking environments.

NEW HPE J9540A 92x 1GB PoE+ RJ45 4x 1GB SFP 8x Open Mod Slots Switch w/ Premium


Specifications

  • Network Ports : 92x 1 Gigabit Ethernet PoE+ RJ45 (Through use of Modules)
  • Uplink Ports : 4x 1 Gigabit Ethernet SFP (Through use of Modules)
  • Management Ports : 1x RS-232C DB-9 Console , 1x USB
  • Product Family : 5400zl Series
  • Module Slots and Options : 12x Expansion Module Slots Available (4x Module Slots in use) - 8x Free Expansion Module Slots Slots - Modules Included are 3x J9534A (24x 1 Gigabit PoE+ RJ45), 1x J9535A (20x 1 Gigabit PoE+ RJ45 4x 1 Gigabit SFP)
  • Expansion Module Options : J9546A, J8708A, J8707A, J9309A, J9538A, J9536A, J9535A, J9537A, J9637A, J8702A, J9308A, J8705A, J8706A, J9307A, J9534A, J9478A, J9547A, J9550A, J9549A, J9548A, J9857A, J9858A
  • Firmware Version : Premium Software
  • Power Supplies Included : 2x J9306A Power Supplies included - 4x Power Supply Slots - 2x Power Supplies required - Power Supply options are - 1500W (J8713A), 875W (J8712A) (Not included)
  • PoE Budget : 2760W
  • Switching Capacity : 758.4 Gbps
  • Forwarding Rate : 564.2 Mpps
  • MAC Address Table Size : 64000
  • Latency : < 3.7 µs (FIFO 64-byte packets) (1000Mb)
  • Rack Mounts : Included
  • Model Number : J9540A
  • Part Number : J9540A, J9540AR
  • Condition : New


Included

  • One (1) NEW HPE J9540A 92x 1GB PoE+ RJ45 4x 1GB SFP 8x Open Mod Slots Switch w/ Premium as described above
