The HPE Aruba JL001A switch offers 92x 1GB RJ45 ports, four 10GB SFP+ ports, and eight free expansion module slots for enhanced connectivity. With a switching capacity of 1920 Gbps and a forwarding rate of up to 1142.8 Mpps, this switch is designed to handle high volumes of data efficiently.
The MAC address table size is robust at 64000 entries, ensuring seamless communication between devices on the network. Regarding latency, the switch boasts an impressive performance with less than 2.8 microseconds for FIFO queued packets at speeds up to gigabit per second.
Aruba JL001A: 92 RJ45 auto-sensing 10/100/1000 PoE+ ports. 4 open 10GbE SFP+ transceiver slots; 8 open module slots; Supports a maximum of 288 autosensing 10/100/1000 ports or 288 SFP ports, 96 SFP+ ports or 96 HPE Smart Rate Multi-Gigabit or 24 40GbE ports, or a combination.
- Network Ports : 92x 1 Gigabit Ethernet PoE+ RJ45 (Through the use of the J9986A Module - See "Included Modules") |
- Uplink Ports : 4x 10 Gigabit Ethernet SFP+ (Through the use of the J9990A Module- See "Included Modules")
- Management Ports : 1x RJ45 Serial Console, 1x AUX, 1x OOBM, 1x console mini-USB Type B (J9827A Module - See "Included Modules")
- Product Family : 5400R zl2 Series
- Module Slots and Options : 12x Interface Module Slots, 2x Management Module Slots (Top of Chassis)
- Included Modules : 1x J9827A (Aruba 5400R zl2 Management Module), 3x J9986A (Aruba 24x 1 Gigabit PoE+ RJ45 MACsec v3 zl2), 1x J9990A (20x 1 Gigabit PoE+ RJ45, 4x 10 Gigabit SFP+ MACsec v3 zl2) - 8x Free Module Slots
- Fan Modules AirFlow Direction : 1x J9832A HPE 5412R zl2 Switch Fan Tray Included
- Power Supplies Included : 0x PSU's Included - 4x Total PSU Slots - 1x Min PSU required (ordered separately) - Options are J9828A (700W), J9829A (1100W), J9830A (2750W)
- Switching Capacity : 1920 Gbps
- Forwarding Rate : up to 1142.8 Mpps
- MAC Address Table Size : 64000
- 1000Mb Latency : < 2.8 µs (FIFO 64-byte packets)
- Rack Mounts : Included (7-RU)
- Model Number : JL001A
- Part Number : JL001A, 5412R 92GT PoE+/4SFP+
- Condition : Seller refurbished
- One (1) Seller Refurbished Aruba HPE JL001A 92x 1GB RJ45 4x 10GB SFP+ 8x Free Exp Module Slot Switch as described above
- One (1) Fan Module Included
- Two (2) Network Modules Included
- One (1) Management Module Included
- One (1) Set of Rack Mount Brackets Included
- Manuals or product brochures are not included. Software or Firmware DVDs or CDs are not included
Product information and installation instructions may be found on the manufacturer's website or the web. Software or firmware updates may be available through the manufacturer's website - Power Cord Not Included
- Power Supplies Not Included
- Transceiver Modules Not Included
