The HPE Aruba JL662A CX 6300 Series is a high-performance switch suitable for modern network requirements. Its 24x 1GB PoE+ RJ-45 ports and 4x 25GB SFP56 ports provide flexibility in connecting various devices.
This switch offers an impressive switching capacity of up to 448 Gbps, ensuring fast and reliable data transfers within your network. With a forwarding rate of approximately 334 Mpps (million packets per second), you can experience smooth traffic flow even during peak usage.
Designed to handle large-scale deployments, this switch's MAC Address Table Size can accommodate up to 32,768 entries. It also has ample power capabilities as the PoE budget reaches 720W, ideal for powering multiple PoE enabled devices like IP phones or wireless access points.
Aruba JL662A: Aruba 6300M Switch with 24x 1GbE RJ45 PoE+ ports, 4x SFP56 ports.
- Network Ports : 24x 1 Gigabit Ethernet PoE+ RJ-45
- Uplink Ports : 4x 1/10/25/50 Gigabit Ethernet SFP56 (Also used as stacking ports)
- Management Ports : 1x USB-C Console Port, 1x OOBM, 1x USB Type A Host, 1x Bluetooth dongle to be used with CX Mobile App
- Stacking Ports : SFP56 Uplink ports are used for stacking - They support speeds of 1GB, 10GB, and 25GB for a total of up to 200 Gbps of stacking throughput per switch
- Stacking Options : Support for up to 10 switches (or members) in a stack via chain or ring topology
- Stacking Cable Options : 10GB = J9281D, J9283D | 25GB = JL487A, JL488A, JL489A | 50GB = R0M46A, R0M47A
- AirFlow Direction : Front-to-Back Airflow
- Fan Module Options : 1x JL669A Fan Tray Included - 2x Fan Tray Slots - JL761A is an option for Back-to-Front Airflow
- Power Supplies Included : 2x PSU Slots - None Included - 1x Min Required - Ordered Separately
- Power Supply Options : JL086A (680W AC), JL087A (1050W AC), JL670A (1600W AC)
- PoE Budget : 720W
- Switching Capacity : 448 Gbps
- Forwarding Rate : 334 Mpps
- MAC Address Table Size : 32,768
- 1Gbps : = 2.28μSec, 10Gbps = 1.46μSec, 25Gbps = 1.90μSec, 50Gbps = 3.49μSec
- DRAM and Flash : 8GB DDR4, 32GB eMMC
- Model Number : JL662A
- Part Number : JL662A, JL662A#ABA
- Condition : New
- One (1) NEW HPE Aruba JL662A CX 6300 Series 24x 1GB PoE+ RJ-45 4x 50 SFP56 Switch as described above
