NEW Cisco N3K-C3232C 32x 100GB QSFP28 2x 10GB SFP+ Front-to-Back Airflow Switch
New

NEW Cisco N3K-C3232C 32x 100GB QSFP28 2x 10GB SFP+ Front-to-Back Airflow Switch

$ 3,459.99
Only 1 remaining
In stock means that we have the product available to meet your delivery commitment. If it is on the web site, it is available for sale and we can ship it that day.   Call if you need more
Shipping: OVERNIGHT OPTION
Cutoff Ground / 3 day / 2 day - 2pm PT, Cutoff Overnight - 5pm PT. Overnight orders after 4pm PT require approval. Call 800-430-6950 to confirm overnight orders after 4pm PT.
Condition: New
New in Original Manufacturers Box. Sold with warranty from NetworkTigers or the manufacturer.
Warranty: 365 days
Warranty coverage period
SKU: NSN-8247
UPC: 889728036146

Overview

The Cisco N3K-C3232C switch offers high performance with a switching capacity of 6.4 Tbps and a forwarding rate of 3.3 Bpps, making it ideal for data-intensive applications. With its front-to-back airflow design, this switch helps maintain optimal cooling in your network environment.

Equipped with 32x 100GB QSFP28 ports and 2x 10GB SFP+ ports, the Cisco N3K-C3232C provides flexibility for various connectivity needs. The MAC address table size of up to 40,000 entries ensures efficient traffic flow handling within the network.

Featuring low latency at just 450ns, this switch enables fast data transmission without delays.

Cisco N3K-C3232C: Nexus 3232C 32 x 100G,1RU switch. Front-to-Back Airflow (Port Side Intake/ Reversed Airflow).


Specifications

  • Network Ports : 32x 100 Gigabit Ethernet QSFP28
  • Uplink Ports : 2x 10 Gigabit Ethernet SFP+
  • Management Ports : 1x Gigabit Management RJ45, 1x RS-232 Serial Console, 1x USB (TypeA)
  • Product Family : Nexus 3200 Series
  • System Memory : 8GB DRAM. 64 GB Flash
  • AirFlow Direction : Front-to-Back Airflow (Port Side Intake/ Reversed Airflow)
  • Fan Modules : 4x NXA-FAN-30CFM-B (3+1) Fan Modules included
  • Power Supplies : 2x NXA-PAC-650W-PI PSU's Included
  • Switching Capacity : 6.4 Tbps
  • Forwarding Rate : 3.3 Bpps
  • MAC Address Table Size : 40,000
  • Maximum number of Longest-Prefix-Match (LPM) routes : 128,000
  • Maximum number of IP host entries : 72,000
  • Maximum number of Layer 3 multicast entries : 64,000
  • VLANs Supported : 4096
  • Packet Buffer : 16MB
  • Latency : 450ns
  • CPU : 4 Core
  • Model Number : N3K-C3232C
  • Part Number : N3K-C3232C, N3K-C3232C=, N3K-C3232C-WS
  • Condition : New

Datasheet

More information on this Cisco N3K-C3232C.

Included

  • One (1) NEW Cisco N3K-C3232C 32x 100GB QSFP28 2x 10GB SFP+ Front-to-Back Airflow Switch as described above

Not Included

  • Manuals or product brochures are not included. Software or Firmware DVDs or CDs are not included
    Product information and installation instructions may be found on the manufacturer's website or the web. Software or firmware updates may be available through the manufacturer's website
