Cisco N3K-C3524P-XL Nexus 3500 24x 10GB SFP+ Front-to-Back Airflow Switch

Cisco N3K-C3524P-XL Nexus 3500 24x 10GB SFP+ Front-to-Back Airflow Switch

Ask for quote
Shipping: OVERNIGHT OPTION
Cutoff Ground / 3 day / 2 day - 2pm PT, Cutoff Overnight - 5pm PT. Overnight orders after 4pm PT require approval. Call 800-430-6950 to confirm overnight orders after 4pm PT.
Condition: Seller refurbished
Pre-owned, tested by qualified techs, working, reset-to-factory default, grade A condition, and parts needed for normal functions are included (as described in the listing).
Warranty: 365 days
Warranty coverage period
SKU: NSB-7027
UPC: 882658631207

Overview

The Cisco N3K-C3524P-XL Nexus 3500 switch offers a high switching capacity of 480 Gbps and a forwarding rate of 360 Mpps, making it suitable for data-intensive networking environments. With its front-to-back airflow design, this switch ensures efficient cooling to maintain optimal performance.

The MAC Address Table Size of up to 64,000 allows for effective address resolution in large-scale networks. Equipped with 24x 10GB SFP+ ports, the N3K-C3524P-XL provides reliable connectivity options for various network configurations. This switch is designed to meet the demands of modern business networking requirements while offering scalability and flexibility.

Cisco Nexus N3K-C3524P-XL: 24x 10 Gigabit Ethernet SFP+. Dual redundant, hot-swappable power supplies. Front-to-Back Airflow (Port Side Intake/ Reversed Airflow).


Specifications

  • Network Ports : 24x 10 Gigabit Ethernet SFP+ (48 Total Ports - 24 enabled)
  • Product Family : Nexus 3500 Series
  • Management Ports : 2x USB, 1x GE Management RJ45, 1x RS-232, 1x 1-PPS timing port, with the RF1.0/2.3 QuickConnect connector type
  • AirFlow Direction : Front-to-Back Airflow (Port Side Intake/ Reversed Airflow)
  • Fan Module Options : 4x NXA-FAN-30CFM-B - Fan Modules
  • Power Supplies Included : 2x N2200-PAC-400W-B AC Power Supplies Included
  • Switching Capacity : 480 Gbps
  • Forwarding Rate : 360 Mpps
  • MAC Address Table Size : 64,000
  • Model Number : N3K-C3524P-XL
  • Part Number : N3K-C3524P-10G, N3K-C3524P-10G, N3K-C3524P-10G=, N3K-C3524P-10G-WS, N3KC3524P10G
  • Condition : Seller refurbished

Datasheet

More information on this Cisco N3K-C3524P-XL.

Included

  • One (1) Seller Refurbished Cisco N3K-C3524P-XL Nexus 3500 24x 10GB SFP+ Front-to-Back Airflow Switch as described above
  • Two (2) Power Cords Included
  • Two (2) AC Power Supplies Included
  • Four (4) Fan Modules Included

Not Included

  • Manuals or product brochures are not included. Software or Firmware DVDs or CDs are not included
    Product information and installation instructions may be found on the manufacturer's website or the web. Software or firmware updates may be available through the manufacturer's website
  • Transceiver Modules Not Included
  • Rack Mount Rails Not Included
