The Cisco N9K-C9396PX is a high-performance switch designed for data centers. It provides fast connectivity options for network devices with 48x 10GB SFP+ and 12x 40GB QSFP+ ports. The front-to-back airflow design ensures efficient cooling in rack environments.
Equipped with a switching capacity of up to 1.92 Tbps and a forwarding rate of up to 1500 mpps, this switch offers excellent performance for demanding workloads. It also features a MAC address table size of up to 96,000 entries.
Ideal for large-scale deployments, the N9K-C9396PX delivers reliable and scalable networking capabilities without having an effect on speed or efficiency.
Cisco Nexus N9K-C9396PX: Nexus 9300 with 48p 1/10G SFP+ and 12p 40G QSFP+. Front-to-Back Airflow (Port Side Intake /Reversed Airflow).
- Network Ports : 48x 10 Gigabit Ethernet SFP+
- Uplink Ports : See "Module Slots and Options"
- Management Ports : 1x RS-232 console port, 1x Out-of-band Management port, 2x USB 2.0 ports
- Product Family : Nexus 9300 Series
- Module Slots : 1x N9K-M12PQ Module Included - 12x 40 Gigabit Ethernet QSFP+
- Module Options : N9K-M6PQ-E, N9K-M6PQ, N9K-M12PQ, N9K-M4PC-CFP2
- AirFlow Direction : Front-to-Back Airflow (Port Side Intake /Reversed Airflow)
- Fan Module Options : 3x N9K-C9300-FAN2 Fan Modules Included
- Power Supplies Included : 2x N9K-PAC-650W AC Power Supplies Included
- Switching Capacity : 1.92 Tbps
- Forwarding Rate : 1500 Mpps
- MAC Address Table Size : 96,000
- Model Number : N9K-C9396PX
- Part Number : N9K-C9396PX, N9K-C9396PX=, N9K-C9396PX-WS
- Condition : Seller refurbished
- One (1) Seller Refurbished Cisco N9K-C9396PX 48x 10GB SFP+ 12x 40GB QSFP+ Front-to-Back Airflow Switch as described above
- Two (2) Power Cords Included
- Two (2) AC Power Supplies Included
- Three (3) Fan Modules Included
- One (1) Network Uplink Module Included
- Manuals or product brochures are not included. Software or Firmware DVDs or CDs are not included
Product information and installation instructions may be found on the manufacturer's website or the web. Software or firmware updates may be available through the manufacturer's website - Transceiver Modules Not Included
- Rack Mount Rails Not Included
