The Cisco N9K-C9396PX is a high-performance switch for data centers and enterprise networks. It features 48 ports of 10GB SFP+ connectivity, allowing for fast and efficient network connections. It has 12 ports of 40GB QSFP+, providing flexible options for higher bandwidth requirements.
With a switching capacity of 1.92 Tbps and a forwarding rate of up to 1500 mpps (million packets per second), this switch can easily handle heavy data traffic. The MAC address table size is also impressive at 96,000 entries, ensuring effective communication within the network.
Cisco's back-to-front airflow design enhances cooling efficiency in rack-mounted deployments while optimizing energy consumption. It incorporates advanced features such as Virtual Extensible LAN(VXLAN), enabling seamless extension across geographical locations. The comprehensive platform supports multi-protocol environments, including IP multicast routing protocols like PIM-SM, PIM-SSM, etc.
Cisco Nexus N9K-C9396PX: Nexus 9300 with 48x 1/10G SFP+ and 12x 40G QSFP+. Back to Front Airflow (Port Side Exhaust /Forward Airflow).
- Network Ports : 48x 10 Gigabit Ethernet SFP+
- Uplink Ports : See "Module Slots and Options"
- Management Ports : 1x RS-232 console port, 1x Out-of-band Management port, 2x USB 2.0 ports
- Module Slots : 1x N9K-M12PQ Module Included - 12x 40 Gigabit Ethernet QSFP+
- Module Options : N9K-M6PQ-E, N9K-M6PQ, N9K-M12PQ, N9K-M4PC-CFP2 - Not Included
- AirFlow Direction : Back to Front Airflow
- Fan Module Options : 3x N9K-C9300-FAN2-B Fan Modules Included
- Power Supplies Included : 2x N9K-PAC-650W-B AC Power Supplies Included
- Switching Capacity : 1.92 Tbps
- Forwarding Rate : 1500 mpps
- MAC Address Table Size : 96,000
- Model Number : N9K-C9396PX
- Part Number : N9K-C9396PX, N9K-C9396PX=, N9K-C9396PX-WS
- Condition : Seller refurbished
- One (1) Seller Refurbished Cisco N9K-C9396PX 48x 10GB SFP+ 12x 40GB QSFP+ Back-to-Front Airflow Switch as described above
- Two (2) Power Cords Included
- Two (2) AC Power Supplies Included
- Three (3) Fan Modules Included
- One (1) Network Uplink Module Included
- Manuals or product brochures are not included. Software or Firmware DVDs or CDs are not included
Product information and installation instructions may be found on the manufacturer's website or the web. Software or firmware updates may be available through the manufacturer's website - Transceiver Modules Not Included
- Rack Mount Brackets/Rails Not Included
