NEW Cisco C9300L-48UXG-2Q-E 48x 1GB UPoE RJ45 (12x MultiGB) 2x QSFP+ Switch
New

NEW Cisco C9300L-48UXG-2Q-E 48x 1GB UPoE RJ45 (12x MultiGB) 2x QSFP+ Switch

Ask for quote
Shipping: OVERNIGHT OPTION
Cutoff Ground / 3 day / 2 day - 2pm PT, Cutoff Overnight - 5pm PT. Overnight orders after 4pm PT require approval. Call 800-430-6950 to confirm overnight orders after 4pm PT.
Condition: New
New in Original Manufacturers Box. Sold with warranty from NetworkTigers or the manufacturer.
Warranty: 365 days
Warranty coverage period
SKU: NSN-6537
UPC: 889728174107

Overview

The NEW Cisco C9300L-48UXG-2Q-E switch is a high-performance networking device for enterprise-level use. It offers 48x 1GB UPoE RJ45 ports, allowing you to connect multiple devices with power over Ethernet support. It features 12 MultiGB (multi-gigabit) ports and 2 QSFP+ (Quad Small Form Pluggable Plus) ports.

With a PoE budget of up to 675W, this switch provides sufficient power supply for demanding applications or connected devices such as IP phones or wireless access points. Its switching capacity reaches an impressive speed of up to 472 Gbps without stacking and can be increased further when stacked, reaching up to 792 Gbps.

The forwarding rate is approximately 351.19 Mpps but can reach higher rates with stacking - around 58928 Mpps. The MAC address table size of the C9300L model can handle up to 32,000 entries.

NEW Cisco C9300L-48UXG-2Q-E 48x 1GB UPoE RJ45 (12x MultiGB) 2x QSFP+ Switch


Specifications

  • Network Ports : 36x 1 Gigabit Ethernet RJ45 UPOE ,12x MultiGigabit Ethernet RJ45
  • Uplink Ports : 2x 40 Gigabit Ethernet QSFP+
  • Management Ports : 2x USB, 1x Mini USB
  • Stack Technology : StackWise-320
  • Stacking Options : C9300L-STACK-KIT - Ordered Separately
  • Supported Stack Members : Other C9300L SKUs with same license level (Number of Members - 8)
  • Switch Version : Network Essentials
  • Fan Module Options : 3x FAN-T2 Modules Included
  • Power Supplies Included : 1x PWR-C1-1100WAC-P Included - 2nd Power Supply ordered separately.
  • PoE Budget : 675W
  • Switching Capacity : 472 Gbps (Switching Capacity with Stacking - 792 Gbps)
  • Forwarding Rate : 351.19 Mpps (Forwarding Rate with Stacking - 589.28 Mpps)
  • MAC Address Table Size : 32,000
  • : Included (1-RU)
  • Model Number : C9300L-48UXG-2Q-E
  • Part Number : C9300L-48UXG-2Q-E, C9300L-48UXG-2Q-E=, C9300L-48UXG-2Q-E-WS
  • Condition : New


Included

  • One (1) NEW Cisco C9300L-48UXG-2Q-E 48x 1GB UPoE RJ45 (12x MultiGB) 2x QSFP+ Switch as described above
