NEW Dell S3048-ON-RA 48x 1GB RJ45 4x 10GB SFP+ B-F Air 210-AEDP Switch

Ask for quote

Shipping: OVERNIGHT OPTION

Condition: New

Warranty: 365 days

SKU: NSN-8119

UPC: 011110490254

Dell S3048-ON-RA delivers 48x 1GbE RJ45 ports and 4x 10GbE SFP+ uplinks, supporting high-density networking. Switching capacity reaches 260 Gbps full-duplex and 130 Gbps half-duplex.

Forwarding rate is measured at 131 Mpps for rapid packet processing. MAC address table supports up to 80,000 entries for extensive device connectivity. Latency registers at just 3.7 microseconds, reducing transfer delays in data transmission. Airflow direction follows B-to-F configuration for cooling efficiency within rack deployments.

Dell S3048-ON: Dell S3048-ON High-Density 1000BASE-T Switch - Front-to-Back Airflow (I/O Panel to PSU Airflow - Normal Airflow).

Network Ports : 48x 1 Gigabit Ethernet RJ45
Uplink Ports : 4x 10 Gigabit Ethernet SFP+
Management Ports : 1x RJ45 Console/Management port with RS232 signaling
Stacking Ports : 2x Stacking ports
Stacking Cable Options : WYDVP - 0.25m, GG661 - 1m, N7T3J - 3m - Not Included
Switch Version : OS9
AirFlow Direction : Back-to-Front Airflow (PSU to I/O Panel Airflow - Reversed Airflow)
Power Supplies Included : 1x PSU Included - 2x Total Slots
Alternative Dell Part Numbers : RWJ77, 210-AEDP
Switching Capacity : 260Gbps (full-duplex), 130 Gbps (half-duplex)
Forwarding Rate : 131 Mpps
MAC Address Table Size : 80,000
Latency : 3.7 usec
: Not Included - 770-BBGY Rail Kit can be ordered separately.
Model Number : S3048-ON-RA
Part Number : S3048-ON-RA, RWJ77, 210-AEDP
Condition : New
