NEW Extreme 16410 X460-48xDC X460 Series 48x 1GB SFP 2x Module Slot (DC) Switch

Ask for quote

Shipping: OVERNIGHT OPTION

Condition: New

Warranty: 365 days

SKU: NSN-7256

The Extreme 16410 X460-48xDC switch features 48x 1Gb SFP ports and two module slots, delivering a switching capacity of 320 Gbps with a forwarding rate of 160.7 Mpps.

It supports an expansion module slot but does not include any modules. Compatible options are the XGM3-2SF (16117) supporting dual-port 10GbE SFP+, XGM3S-2XF (16119) for dual-port 10GbE XFP, and XGM3S-2SF (16126) offering dual-port 10GbE SFP+. The MAC address table size is set at up to 32,000 entries. This DC-powered switch provides efficient processing for data-intensive operations while maintaining flexibility through its modular configuration capability.

Extreme 16410: X460-48xDC - 48 100/1000BASE-X unpopulated SFP, slot for optional XGM3 module(s), slot for optional stacking module, DC PSU with one unpopulated PSU slot, Fan module, ExtremeXOS Edge license.

Network Ports : 48x 1 Gigabit Ethernet SFP
Management Ports : 1x DB-9 Serial, 1x Fast Ethernet RJ45, 1x USB
Stacking Ports : 1x Stacking Module Slot - Not Included
Stacking Options : 16419 (SummitStack 40 Gbps), 16420 (SummitStack-V80 80Gbps high-speed stacking or SummitStack-V longer distance stacking) - Not Included
Module Slots : 1x Expansion Module Slot - Expansion Modules not included
Module Options : 16117 (XGM3-2SF 10 Gigabit SFP+), 16119 (XGM3S-2xf/module 2 x 10GbE XFP), 16126 (XGM3S-2sf/module 2 x 10GbE SFP+) - Not Included
Switch Version : ExtremeXOS Edge
Fan Module Options : 1x Fan Module
Power Supplies Included : 1x DC PSU - 2x Slots - 2nd Power Supply ordered separately.
Switching Capacity : 320 Gbps
Forwarding Rate : 160.7 Mpps
MAC Address Table Size : 32,000
: Included (1-RU)
Model Number : 16410
Part Number : 16410, X460-48xDC
Condition : New
