NEW Cisco WS-C3750X-24P-E 24x 1GB PoE+ RJ45 1x Module Slot Switch

Ask for quote
Shipping: OVERNIGHT OPTION
Cutoff Ground / 3 day / 2 day - 2pm PT, Cutoff Overnight - 5pm PT. Overnight orders after 4pm PT require approval. Call 800-430-6950 to confirm overnight orders after 4pm PT.
Condition: New
New in Original Manufacturers Box. Sold with warranty from NetworkTigers or the manufacturer.
Warranty: 365 days
Warranty coverage period
SKU: NSN-2803
UPC: 882658517181

Overview

The Cisco WS-C3750X-24P-E is a 1GB PoE+ switch designed to enhance network efficiency. It features 24 RJ45 Ethernet ports supporting Power over Ethernet Plus (PoE+) with up to 30W per port, making it suitable for powering IP phones and cameras.

The switch includes one module slot offering flexibility in connectivity options like uplinks or stacking modules based on user needs. Its switching capacity reaches 160 Gbps, while the forwarding rate supports traffic at speeds of up to 65.5 Mpps, ensuring efficient data transfer.

Cisco Catalyst WS-C3750X-24P-E : Stackable 24 10/100/1000 Ethernet PoE+ ports, with 715W AC Power Supply 1 RU.


Specifications

  • Network Ports : 24x 1 Gigabit Ethernet PoE RJ45
  • Management Ports : 1x USB Type A, 1x Console - Mini-USB Type B Management, 1x RS-232 - RJ45 Management, 1x Gigabit RJ45 Management
  • Stacking Ports : 2 x StackWise 480 ports, 2 x StackPower connection ports - Cables sold separately
  • Module Slots and Options : 1x Slot - Sold Separately - Options are - C3KX-NM-1G, C3KX-NM-10G, C3KX-NM-10GT, C3KX-SM-10G
  • Firmware Version : IP Services
  • Fan Modules AirFlow Direction : 2x C3KX-FAN-23CFM - Fan Modules
  • Power Supplies Included : 1x C3KX-PWR-715WAC - AC 715W (1x Ships Default - Dual Capable) Options are - C3KX-PWR-350WAC, C3KX-PWR-715WAC, C3KX-PWR-1100WAC - DC Power available with C3KX-PWR-440WDC.
  • Switching Capacity : 160 Gbps
  • Forwarding Rate : 65.5 Mpps
  • MAC Address Table Size : Access - 4000, Default - 6000, Routing - 3000, VLAN - 12000
  • Rack Mounts : Included (1-RU)
  • Model Number : WS-C3750X-24P-E
  • Part Number : WS-C3750X-24P-E, WS-C3750X-24P-E=, WS-C3750X-24P-E-WS
  • Condition : New


Included

  • One (1) NEW Cisco WS-C3750X-24P-E 24x 1GB PoE+ RJ45 1x Module Slot Switch as described above
